Product Description
ISOSCOPE® DMP10 (Basic)/ DMP30 (Advanced)– Coating Thickness Gauges for Non-Ferrous Metals
The ISOSCOPE® DMP10 and DMP30 are precision handheld instruments for non-destructive measurement of non-conductive coatings on non-ferrous, electrically conductive metals using the amplitude-sensitive eddy current method (DIN EN ISO 2360). Ideal for applications involving aluminum, copper, brass, and anodized layers, both models are built for durability, ergonomic ease, and reliable performance in manufacturing, aerospace, automotive, electronics, and quality control environments.
While the DMP10 offers dependable measurement and storage for up to 10,000 readings, the DMP30 adds enhanced capabilities—Bluetooth® connectivity, haptic feedback, and expanded memory (250,000 readings in 2,500 batches)—making it the ideal choice for users needing advanced data handling and wireless workflow integration.
? Key Features
- Eddy current method for non-conductive coatings on non-ferrous, conductive substrates (ISO 2360)
- IP64-rated all-aluminum housing: dustproof, shockproof, and water-resistant
- Compact, ergonomic handheld design with intuitive one-handed 4-key operation
- Rotatable, high-contrast color display for optimal readability from any angle
- Visual and acoustic tolerance alerts (DMP30 adds haptic feedback)
- USB interface for data transfer (DMP30 includes Bluetooth® dongle for wireless transfer)
- Rechargeable lithium battery offering up to 24 hours of operation
- Multilingual menu navigation in 22 languages
- Compatible with Fischer’s digital and legacy F-probes (via optional adapter)
- Integrated graphical user prompts for guided measurements
- Tactile Suite® software for streamlined data analysis and reporting
- DMP30 only: 250,000 reading memory across 2,500 batches (vs. 10,000 readings on DMP10)
⚙️ Technical Attributes
|
Attribute |
DMP10 (Basic) |
DMP30 (Advanced) |
|
Measurement Method |
Amplitude-sensitive eddy current |
Amplitude-sensitive eddy current |
|
Substrate |
Al, Cu, CuZn, other conductive metals |
Al, Cu, CuZn, other conductive metals |
|
Coatings Measured |
Paint, lacquer, plastic, anodized layers |
Paint, lacquer, plastic, anodized layers |
|
Display |
Rotatable color, high-contrast |
Rotatable color, high-contrast |
|
Battery Runtime |
Up to 24 hours |
Up to 24 hours |
|
Memory Capacity |
10,000 readings |
250,000 readings / 2,500 batches |
|
Data Transfer |
USB |
USB + Bluetooth® (dongle included) |
|
IP Rating |
IP64 |
IP64 |
|
Probe Compatibility |
Digital & legacy (via adapter) |
Digital & legacy (via adapter) |
? Delivery Content
- ISOSCOPE® DMP10 or DMP30 instrument (probe required, sold separately)
- Compact carrying case
- Rechargeable lithium battery
- USB interface cable
- Carrying strap with panic lock
- Quick-start guide (English)
- Tactile Suite® software access
- DMP30 only: Bluetooth® USB dongle
⚠️ Note: Measuring probe and external charger are not included. Probes must be purchased separately from Fischer. External charger available optionally.
? Choose Your Model
Choose the ISOSCOPE® DMP10 for dependable, entry-level coating thickness measurement on non-ferrous metals. Step up to the DMP30 for professional-grade performance with large memory storage, wireless connectivity, and advanced feedback—ideal for high-volume inspection workflows and connected digital environments.
