Product Description
DUALSCOPE® DMP20 (BASIC) / DMP40 (ADVANCED)– Dual-Method Coating Thickness Gauges for Ferrous & Non-Ferrous Metals
The DUALSCOPE® DMP20 and DMP40 combine magnetic inductive (DIN EN ISO 2178) and eddy current (DIN EN ISO 2360 / ASTM D7091) measurement methods, allowing fast, accurate coating thickness analysis on both ferrous and non-ferrous substrates. Whether testing paint on steel or anodized layers on aluminum, both models offer precision, durability, and compatibility with Fischer’s digital and legacy probes.
The DMP20 is ideal for everyday, reliable measurements with 10,000-reading memory and USB connectivity. The DMP40 enhances capability with Bluetooth® wireless transfer, haptic feedback, and 250,000-reading storage across 2,500 batches—perfect for high-throughput, digitally connected workflows.
? Key Features
- Dual-method measurement: magnetic induction for ferrous substrates and eddy current for non-ferrous substrates
- IP64-rated aluminum housing: shockproof, dustproof, and water-resistant
- Ergonomic one-handed 4-key interface with intuitive graphical user guides
- Rotatable, high-contrast color display for excellent visibility
- Real-time tolerance alerts: visual and acoustic on both models (DMP40 adds haptic feedback)
- USB interface for data transfer (DMP40 includes Bluetooth® dongle for wireless connectivity)
- Rechargeable lithium battery with up to 24 hours of runtime
- Multilingual menu navigation (22 languages), user-friendly for all experience levels
- Compatible with Fischer digital F-probes and legacy F-probes via optional adapter
- Tactile Suite® software integration for data analysis and reporting
- DMP40 only: Advanced memory (250,000 readings / 2,500 batches) vs. 10,000 readings on DMP20
⚙️ Technical Attributes
|
Attribute |
DMP20 (BASIC) |
DMP40 (ADVANCED) |
|
Measurement Methods |
Magnetic inductive + Eddy current |
Magnetic inductive + Eddy current |
|
Substrate |
Ferrous and non-ferrous metals |
Ferrous and non-ferrous metals |
|
Coatings Measured |
Paint, lacquer, plastic, Zn, Cr, Cu, anodized layers |
Same as DMP20 |
|
Display |
Rotatable, high-contrast color |
Rotatable, high-contrast color |
|
Battery Runtime |
Up to 24 hours |
Up to 24 hours |
|
Memory Capacity |
10,000 readings |
250,000 readings / 2,500 batches |
|
Data Transfer |
USB |
USB + Bluetooth® (dongle included) |
|
IP Rating |
IP64 |
IP64 |
|
Probe Compatibility |
Digital & legacy (with adapter) |
Digital & legacy (with adapter) |
? Delivery Content
- DUALSCOPE® DMP20 or DMP40 instrument (probe required, sold separately)
- Compact carrying case
- Rechargeable lithium battery
- USB interface cable
- Carrying strap with panic lock
- Quick-start guide (English)
- Tactile Suite® software access
- DMP40 only: Bluetooth® USB dongle
⚠️ Note: Measuring probe and external charger are sold separately. Compatible probes must be purchased from Fischer. External charger available as an optional accessory.
Choose Your Model
The DMP20 offers reliable dual-technology performance for technicians who need versatility in a lightweight, field-ready format. Step up to the DMP40 for advanced digital workflows—featuring wireless connectivity, large-scale memory, and haptic feedback—designed for production environments, audit documentation, and data-driven QA systems.
