Product Description
PosiTest®
Magnetic Coating Thickness Gages for Non-Magnetic Coatings on Steel
PosiTest magnetic pull-off thickness gage (banana gauge) for the non-destructive measurement of non-magnetic coatings (paint, enamel, galvanizing, metalizing, plating, etc.) on steel.
- Highly wear resistant Carbide Probe for longest life and continuous accuracy
- Extra rugged housing, not affected by mechanical shock, water, acid or solvents
- Unique overall design, fully supported, positive positioning, no pivoting tendencies during measurement
- Positive visual and audible indicators to designate when thickness reading is established
- “V” grooves in probe housing and gage base allow correct positioning on cylindrical objects
- Certificate of Calibration showing traceability to PTB included (Long Form)
Conforms to ASTM D7091/B499, ISO 2808 and others
Features
Accurate
- Certificate of Calibration showing traceability to PTB included with every gage
- Matching Calibration Standards and Procedures available for every model
- Highly wear resistant Carbide Probe for longest life and continuous accuracy
- Remove center of dial cover for easy calibration adjustment
- Conforms to national and international standards
Durable
- Extra rugged housing, not affected by mechanical shock, water, acid or solvents
- Unique overall design, fully supported, positive positioning, no pivoting tendencies during measurement
- Can be used fully supported or with only the front probe area contacting the surface
- Functions on a permanent rare-earth cobalt magnet
- No batteries/electronics
- 2 year warranty
Easily measures small parts of almost any shape
Simple
- Positive visual and audible indicators to designate when thickness reading is established
- “V” grooves in probe housing and Gage base allow correct positioning on cylindrical objects
- Compact, lightweight, precisely balanced, independent of gravity – can be used in any position
- GO/NO-GO button can be pre-set for rapid measurement
- Probe contact and dial rotation all in a one-finger operation
- Furnished with wrist strap and instructions in a high quality leather case with belt loops for your convenience
DeFelsko PosiTest Pull-off Gages: 4 Models Available
 |
 |
 |
 |
| PosiTest FM | PosiTest F | PosiTest GM | PosiTest G |
| APPLICATION | APPLICATION | APPLICATION | APPLICATION |
| Hot dip galva-nizing, hard chrome metalizing, paint, enamel, plastic coatings on steel. | Hot dip galva-nizing, hard chrome metalizing, paint, enamel, plastic coatings on steel | Electro-plating, thin paint films, phosphating on steel |
Electro-plating, thin paint films, phosphating on steel |
| SCALE | SCALE | SCALE | SCALE |
| 0-80 mils | 0-2000 µm | 0-8 mils | 0-200 µm |
| TOLERANCE | TOLERANCE | TOLERANCE | TOLERANCE |
| ± 0.2 mils up to 4 mils ±5% of the reading over 4 mils |
±5 µm up to 100 µm ±5% of the reading over 100 µm |
±0.04 mils up to 0.8 mils ±5% of the reading over 0.8 mils |
±1 µm up to 20 µm ±5% of the reading over 20 µm |
